Radiology of Abdomen, Pelvis, and Perineum -- Normal Upper GI Series (UGI)

The Structural Basis of Medical Practice -- Human Gross Anatomy

The Pennsylvania State University College of Medicine
This site has been accessed  times since October 13, 1998

Note:  This is an AP supine film after barium has been swallowed.  There are surgical clips in the right upper abdomen from a previous cholecystectomy (removal of the gall bladder).  The patient is lying on his back.  In the supine projection the barium will pool in the fundus and air will rise to the antrum of the stomach.

Identify -- fundus, body, and antrum of stomach, duodenum, jejunum, ileum

To view at full resolution right mouse click on image and select "view image."
